Cambium Networks' proven Point-to-Point (PTP) series solutions are deployed worldwide, serving highly critical applications in formidable environments for the world’s most demanding users. With best-in-class real-world performance and FIPS 140-2 approved security available for government and military applications, the PTP series is your connection to what matters, no matter what.
Sub 6 Unlicensed
PTP 450b Backhaul
The PTP 450b features up to 300 Mbps in a 40 MHz channel. Frequency range is 4.9 – 5.925 GHz.
PTP 450b High Gain Backhaul
Up to 300 Mbps in a 40 MHz channel. Frequency range is 4.9 – 5.925 GHz
PTP 670 systems provide 4.9 to 6.05 GHz, multi-band flexibility in a single radio and operate in channel sizes from 5 to 45 MHz.
PTP 550 - 6 GHz Unlicensed Band Solution featuring DCS & AES
Point-to-Point Gigabit+ Capacity
PTP 550 is a Point to Point Gigabit throughput solution based on 802.11ac Wave 2 operating in 5 GHz wireless space, addressing the gigabit capacity needs for high-speed backhaul solutions in short range and middle range applications. Provides up to 1.36 Gbps throughput with ARQ and asymmetric non-contiguous channel aggregation across 5 GHz band. The PTP 550 solution draws its attributes from Cambium Networks’ Point to Point products such as PTP 650/670 and PTP 450i. Each PTP 550 radio is enclosed in a rugged IP66/67 rated metal enclosure, which protects the radio from extreme conditions and solar radiation.
PTP 450i Backhaul
The ultra-wide band PTP 450i Integrated features dynamic interference filtering, IP-66/67 enclosure, and multifunction AUX port. The PTP 450i boasts triple the power and range of a 450 product, along with ruggedization to withstand industrial and public safety environments. Available as PMP or PTP.
PTP 700 - Wireless Broadband Solution with FIPS 140-2 & MIL-STD-810G Standards
One radio — many missions.
PTP 700 is a Point-to-Point wireless broadband solution for mission-critical communications in government, industrial, and public safety spaces. With FIPS 140-2 and NTIA certification, PTP 700 is available in two models: Connectorized, and Connectorized+Integrated – allowing for antenna selection at time of deployment.
ePMP Force 300-25
Cambium Networks’ ePMP Force 300-25 is designed to operate in high-interference environments and provides superior throughput of over 500 Mbps of real user data.
The High-gain ePMP Force 300-25 802.11AC Wave 2 solution provides 500+ Mbps peak throughput, always-on spectrum analysis, and local Wi-Fi management.
6-38 GHz Licensed
PTP 820S Backhaul
PTP 820S is an all-outdoor point-to-point licensed microwave unit.
PTP 820C Backhaul
PTP 820C is an all-outdoor, multi-core unit. The PTP 820C has dual-core functionality, enabling the system to operate up to 2 Gbps via software upgrades, eliminating the need for future forklift upgrades, or major system overhaul by the network operator to deliver gigabit-plus capacity.
PTP 820G Backhaul
PTP 820G is a split-Mount / All-Indoor unit, with Multi-Carrier Options
PTP 820C HP Backhaul
All outdoor, dual core, High Power 35 dBm model inter-operable with PTP 820C. The PTP 820C HP has up to 1.2 Gbps and field changeable diplexer.
